ez@zuoyeal.com Technical characteristics
◎The patented forward scattering principle based on soot particles has extremely high sensitivity and resolution, and can continuously measure the emission of ultra-low concentrations of soot particles online.
◎Patented unique extraction heating and return method, which can be used in occasions where the measured gas contains extremely high water mist.
◎Equipped with optional isokinetic sampling module for isokinetic tracking sampling and testing.
◎The adaptive dynamic classification method can measure very low concentrations of smoke and dust particles, and can also measure very high concentrations of smoke and dust. It has an extremely wide dynamic range.
◎Patented automatic zero point and automatic span calibration.
| Project | Indicators |
| Measuring principle | Extractive laser scattering method |
| Measuring Range | 0-10 mg/m3 ,0-100g/m3 (can be customized) |
| Detection limit | ≤0.05mg/m3 |
| Indication error | ±10% |
| Zero and span drift | ≤1.5%F.S./week |
| Isokinetic sampling | 0-35 m/s |
| Signal output | (4-20)mA,RS485,2-way relay output |
| Calibration | Automatic calibration function |
| Condition of measured medium | 10℃-300℃ |
| Compressed air demand | 0.3MPa, not less than 60L/min. |
| Condition of measured medium | 10℃-250℃ |
| Protection level | IP65 |
| Ambient temperature | -20℃-50℃ |
| Power supply | 220±15%（VAC），600W |
| Dust analyzer Size | 550mm*450mm*200mm |
| Dust analyzer Weight | ≤20Kg |
| Sampling rod length | 1.2 meters (customizable) |
